Technical Specifications:
| D-Link DGS-105 Specifications | ||
|---|---|---|
| DGS-105 | DGS-108 | |
| Switching Fabric | 10Gbps | 16Gbps |
| Standards |
|
|
| Protocol | CSMA/CD | |
| Data Transfer Rates |
|
|
| Topology | Star | |
| Network Cables |
|
|
| Media Interface Exchange | Auto MDI/MDIX adjustment for all ports | |
| LED Indicators |
|
|
| Transmission Method | Store-and-forward | |
| MAC Address Table | 2K | 8K |
| MAC Address Learning | Automatic Update | |
| Packet Filtering/Forwarding Rates |
|
|
| RAM Buffer | 128KB per device | |
| Jumbo Frames | 9,000 Bytes | |
| QoS | 4 Queues, strict mode | |
| DC Input | External 5 V/1 A Level "V" Power Adapter | |
| Power Consumption |
|
|
| Heat Dissipation |
|
|
| MTBF | 1,688,338 hours | 2,053,751 hours |
| Operating Temperature | 32 to 130 °F (30 to 50 °C) | |
| Storage Temperature | -14 to 158 °F (10 to 70 °C) | |
| Operating Humidity | 10% to 90% RH non-condensing | |
| Storage Humidity | 5% to 90% RH non-condensing | |
| Dimensions | 3.9 x 3.8 x 1.1 inches (100 x 98 x 28 mm) |
6.3 x 4.0 x 1.1 inches (162 x 102 x 28 mm) |
| Weight | 10.08 ounces (286 grams) | 15.52 ounces (440 grams) |
| Certifications |
|
|
