Leírás és Paraméterek
- Power
-
3000 VA / 1800 W
- Type
-
Line Interactive
- Nominal Input Voltage
-
230 VAC
- Nominal Output Voltage
-
230 VAC
- Accepted Input Voltage Range
-
162-290 VAC
- Frequency
-
50 / 60 Hz Auto detection
- Outlets
-
8 x IEC C13 Battery Backup & Surge Protection
- Transfer Time to Battery / AC
-
<4ms
- Typical Backup Time
-
25% Load - 18 min
50% Load - 7.5 min
75% Load - 4 min
100% Load - <2 min
- Communication Ports
-
RS232 / USB / Intelligent Port (not included in the package)
- Battery Type
-
Sealed and leak proof maintenance
- Battery Specification
-
12V 7.5Ah x 4
- Software
-
Monitor & Control over USB, LAN and Internet (SNMP card optional)
- Features
-
Pure sine wave output
Line-interactive
Auto restart
Auto-Charge
Boost and buck AVR for voltage stabilization
Software management
Off-Mode Charging
Cold start function
Emergency power off function (EPO)
Generator Compatible
Smart SNMP card supported
Rack design
- LCD Display
-
Load level, Battery level, AC mode, Battery mode, Bypass mode, Fault indicators
- Environment
-
Humidity: 0-90 % (nin-condensing)
Temperature: 0-40 grades Celsius
Noise level: less than 50 dB
- Physical Dimensions
-
400 x 438 x 88 mm - 2U Weight: 16.5 kg
