| HARDVER JELLEMZŐK |
| Csatlakozások |
1× 10G Ethernet Port |
| Gomb |
Reset |
| Hálózati tápegység |
802.3at PoE or 12V/2.5A DC |
| Energiafelvétel |
• 25.44 W (For PoE)
• 22.57 W (For DC) |
| Méretek (Sz x Mé x Ma) |
8.7 × 8.7 × 1.3 in (220 × 220 × 32.5 mm) |
| Antenna típusa |
• 2.4 GHz: 2× 4.0 dBi
• 5 GHz: 2× 5.0 dBi
• 6 GHz: 2× 5.0 dBi |
| Bluetooth |
1 × 4.0 dBi, Bluetooth 5.2
*Firmware update may be required. |
| Felszerelés |
Ceiling / Wall Mounting (Kits Included) |
| VEZETÉK NÉLKÜLI JELLEMZŐK |
| Coverage |
140?(1500 ft2)§ |
| Concurrent Clients |
380+** |
| Wi-Fi sztenderd |
IEEE 802.11 a/b/g/n/ac/ax/be |
| Frekvencia |
6 GHz, 5 GHz, and 2.4 GHz |
| Adatátvitel |
574 Mbps (2.4 GHz) + 4320 Mbps (5 GHz) + 5760 Mbps (6 GHz)† |
| Vezeték nélküli funkciók |
• MLO‡
• 4K-QAM‡
• MU-MIMO‡
• HE320‡
• Mesh?
• BSS Coloring‡
• OFDMA‡
• Load Balance
• Band Steering
• Beamforming
• Airtime Fairness
• Multiple SSIDS:24(8 on each band)
• Wireless Schedule
• Reboot Schedule
• QoS(WMM)
• Rate Limit
• Static IP/Dynamic IP
• RADIUS Accounting
• MAC Authentication |
| Vezeték nélküli biztonság |
• Captive Portal Authentication?
• Access Control
• Maximum number of MAC Filter: 4,000
• Wireless Isolation Between Clients
• VLAN
• Rogue AP Detection
• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise |
| Átviteli teljesítmény |
< 25 dBm (2.4 GHz)
< 25 dBm (5 GHz)
< 23 dBm (6 GHz) |
| VEZÉRLÉS |
| Omada App |
Yes |
| Centralized Management |
• Omada Cloud-Based Controller
• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada Software Controller |
| Cloud Access |
Yes. Require the use of an OC300, OC200, Omada Software Controller, or an Omada Cloud-Based Controller. |
| Riasztás e-mailben |
Yes |
| LED ki/bekapcsolás |
Yes |
| Mac-cím alapú vezérlés |
Yes |
| SNMP |
v1, v2c, v3 |
| Syslog helyi/távoli |
Yes |
| Webes felelületű vezérlés |
Yes |
| EGYÉB JELLEMZŐK |
| Tanúsítványok |
CE, FCC, RoHS, IC |
| Csomagolás tartalma |
• EAP773
• Installation Guide
• Ceiling/Wall Mounting Kits
Note: Power Adapter is NOT included. |
| Környezet |
• Operating Temperature: 0 °C–40 °C (32 °F–104 °F);
• Storage Temperature: -40 °C–70 °C (-40 °F–158 °F);
• Operating Humidity: 10%–90% non-condensing;
• Storage Humidity: 5%–90% non-condensing; |
A további hardware verziókkal kapcsolatos információkat a Támogatás menüpont alatt találja.
†Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. The 320 MHz bandwidth is only available on the 6 GHz band. Simultaneously, the 320 MHz bandwidth on the 6 GHz band and 160 MHz bandwidth on the 5 GHz band may be unavailable in some regions/countries due to regulatory restrictions. Double channel width and speed refer to 320 MHz compared to 160 MHz for WiFi 6 routers. Actual wireless data throughput, wireless coverage, and connected devices are not guaranteed and will vary as a result of internet service provider factors, network conditions, client limitations, and environmental factors, including building materials, obstacles, volume and density of traffic, and client location.
‡Use of Wi-Fi 7 (802.11be), Wi-Fi 6 (802.11ax), and features including Multi-Link Operation (MLO), 320 MHz Bandwidth, 6 GHz, 4K-QAM, Multi-RUs, OFDMA, MU-MIMO and BSS Color requires clients to also support the corresponding features.
*Zero-Touch Provisioning and Auto Channel Selection and Power Adjustment require the use of Omada Cloud-Based Controller. Go to /hu/omada-cloud-based-controller/product-list/ to confirm which models are compatible with Omada Cloud-Based Controller.
**The actual capacity depends on the wireless environment and client traffic and is generally less than the maximum number of client connections.
§Coverage value is calculated based on laboratory testing. Actual coverage is not guaranteed and will vary as a result of client limitations and environmental factors.
?Omada Mesh, AI Roaming, Captive Portal, and Cloud Access require the use of an Omada SDN controller. Please refer to the User Guides of Omada SDN controllers for configuration methods. |
