Leírás és Paraméterek
| Installation Type | Wall pole |
| Dimensions without packaging (H x W x D) [mm(in.)] | 200 mm x 200 mm x 69 mm |
| Weight without packaging [kg(lb)] | 1.91 kg |
| Weight with packaging [kg(lb)] | 3.73 kg |
| Power supply mode | PoE |
| Input voltage range [V] | PoE: 802.3at/af |
| Service port surge protection | PoE port: Common mode (8 wires to ground): 6 kV (1.2/50 us, 42 ohms), criterion B Differential mode (48 V-RTN): 0.5 kV (1.2/50 us, 42 ohms), criterion B |
| Maximum number of physical ports on the entire device | GE (RJ45) x 1, 10M/100M/1000M auto-sensing GE SFP x 1 |
| Long-term operating temperature [°C(°F)] | -40°C to 65°C(From 1800 m to 5000 m [5905.51 ft. to 16404.20 ft.], the maximum temperature of the device decreases by 1°C [1.8°F] for every 300 m [984.25 ft.] increase in altitude.) |
| Storage temperature [°C(°F)] | –40°C to +80°C |
| Long-term operating relative humidity [RH] | 0% RH ~ 100% RH |
| Long-term operating altitude [m(ft.)] | –60 m to +5000 m (–196.85 ft to +16404.20 ft) |
| Atmospheric pressure [kPa] | 53kPa - 106kPa ETSI 300 019-2-3 |
| Ground | earthing ground |
| Radio number | 2 |
| MIMO spatial streams | Radio 0 (2.4 GHz): 2x2 Radio 1 (5 GHz): 2x2 |
| Wi-Fi standard | 2.4G:802.11b/g/n/ax 5G:802.11a/n/ac/ac wave2/ax |
| Radio interface | Built-in directional antenna |
| Antenna gain | 2.4G:10dBi 5G:11dBi BLE:5dBi |
| Maximum transmit power | 2.4G: 28dBm(Max) 5G: 27dBm(Max) (note: this is MIMO total radio power, the same as: 2.4G: 25dBm/chain(Max) 5G : 24dBm/chain(Max)) BLE:<10dBm |
