Leírás és Paraméterek
- Network Type
-
EU:
FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz)
TDD-LTE: B38/B40 (2600/2300 MHz)
HSPA+/UMTS: B1/B5/B8 (2100/850/900 MHz)
CN:
FDD-LTE: B1/B3/B5/B8 (2100/1800/850/900 MHz)
TDD-LTE: B38/B40 (2600/2300 MHz)
HSPA+/UMTS: B1/B5/B8 (2100/850/900 MHz) - Wi-Fi Class
-
N300
- Wi-Fi (2.4 GHz)
-
300 Mbps
- Wireless Standards (Invaild)
-
IEEE 802.11b/g/n
- Frequency
-
2.4 GHz
- Reception Sensitivity
-
11g 54M: -74.5 dBm
11n HT20 MCS7: -73.5 dBm
11n HT40 MCS7: -70.5 dBm - Transmission Power
-
-
< 20 dBm (2.4 GHz)
-
- Wireless Security
-
WPA-PSK / WPA2-PSK
- Wireless Functions
-
smart connect
WPS
Wireless Schedule
Wireless Clients Statistics
- Wireless
- Dimensions
-
219 × 140 × 32 mm
(8.62 × 5.51 × 1.26 in)
- Interfaces
-
1× 10/100Mbps LAN/WAN Port
3× 10/100Mbps LAN Ports
1× Nano SIM Card Slot
- Antenna
-
2× External 4G LTE Antennas,
2× External Wi-Fi Antennas - Button
-
WPS?Reset Button
- External Power Supply
-
9V/0.85A
- LED
-
1× Power
1× Internet
1× LAN
3× Signal - LTE Standard
-
Cat 4
150/50Mbps DL/UL
- Hardware
- Operation Mode
-
3G/4G Router
Wireless Router - Cellular Mode
-
4G Preferred
4G Only
3G Only - Cellular APN
-
Data Roaming
Network Search
Profile Create
APN Settings
ISP File Upgrade
PIN Management - WAN Mode
-
Dynamic IP
Static IP
PPPoE
PPTP
L2TP - NAT Forwarding
-
ALG
Virtual Server
Port Triggering
UPnP
DMZ - Protocols
-
IPv4, IPv6
- Data Settings
-
Data Statistics
Data Limit - Parental Controls
-
Time Control
Website Filtering - Guest Network
-
2.4 GHz Guest Network
- DHCP
-
Server
DHCP Client List
Address Reservation - DDNS
-
MERCUSYS DDNS
DynDns
NO-IP - SMS
-
Inbox
New Message
Outbox
Drafts - Security
-
IPv4 SPI Firewall
Access Control
Service Filtering
IP & MAC Binding
IPv6 Firewall - System Settings
-
Time Settings
LED Control
Diagnostics
Firmware Upgrade
Backup&Restore
Reboot
Administration
System Log
CWMP Settings - Device Management
-
MERCUSYS APP
Web GUI - System Language
-
English
Spanish
Italian
Polish
Russian - TR-069
-
√
- Software
- Package Contents
-
300 Mbps Wireless N 4G LTE Router (MB115-4G)
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide
- Environment
-
Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~60°C (-40°F~140°F)
Operating Humidity: 10%~90% Non-Condensing
Storage Humidity: 5%~90% Non-Condensing
- Others
